hd home theater projector screen zhk100b XY Screens Brand hd projector screen
1. By a combination of advanced designs and technologies, our products can provide excellent quality and performance. The warranty period of our products is 12 months
2. We Promise To Meet Customers' Requirement, Xiongyun screens are designed using high quality material, which enhances the picture quality by absorbing the maximum light from the projector resulting in brighter and true color images,Setting Us Apart From Our Competitors, Guangzhou Xiong-Yun Audio-visual Equipment Co., Ltd. Offer Numerous hd home theater projector screen To Enhance Efficiency, If You Have Further Questions. Please Feel Free To Ask Us.
3. We have specialized expertise for providing an elegant variety of hd projector screen in the market. A wide range of Projector Screen is made available, which has been designed using modern technology to impart several beneficial features
4. Raw materials can be processed by HD Home Theater Projector Screen are various, such as hd home projector. The aluminum alloy case is stylish and durable, available in white color.
5. With its easy and adjustable fabric spring system, our Screen is perfectly and permanently tensioned, the users are able to set up in seconds, XY Screens Professionally Manufactures And Supplies hd projector screen, hd home theater projector With Good Performance.
Our Ultra Thin Frame Projection Screen ZHK100B which provides the thinnest visible bezel/frame available in the market today is uniquely designed to resemble a premium LED TV but with much larger viewing area options. ZHK100B Thin Edge Frame uses sturdy extruded aluminum alloy frame with 12mm edge border that offers maximized viewing, making this an excellent addition to both home theater and commercial applications. Watch as your viewing experience soars to new heights of enjoyment!
Excellent picture quality - Suitable for 4K & 3D television/movies.
Installation is easy - With its easy and adjustable fabric spring system, our Fixed Frame Screen is perfectly and permanently tensioned, ensuring that the screen is as flat and level as the mirror. Special designed slim bracket for an easy click on installation, also available as an in-wall display. Therefore, the users are able to set up in seconds.
◆◆ Product Specification
| Frame Material: | Aluminum Alloy |
| Housing Color: | Black / White / Grey / Orange / Blue / Golden Velvet |
| Size: | 80-200 inch / customized |
| Aspect Ratio: | 16:9 / 16:10 / 4:3 / 1:1 / 2.35:1 / customized |
| Frame Width: | 12mm |
| HD: | Yes |
| 3D: | Yes |
| 4K: | Different fabrics are optional |
◆◆ Product Features
◆ Four Sided Tension Design - Spring System
The tension springs along with the fixing lugs stretching and tightening the fabric to make the screen surface completely flat and wrinkle-free
High quality aluminum alloy frame wrapped in velvet.
45° corner connecting bracket, easy to install
The frame adopt special Concave Design
Connecting bar
Corner brace
Seamless Connecting
1. Top Bracket 2. Bottom Bracket 3. Inter Corner Brace 4. External Connecting Bar
5. Connecting Bar 6. Screwdriver 7. Hook(To install the springs) 8. (Accessories of curved frame only )
Product Model | Fabric Model | HD/4K | Support 3D Mode | Sound-Transparent |
|---|---|---|---|---|
| ZHK100B-Black Crystal III | Black Crystal III | HD | Active | No |
| ZHK100B-WF1 Pro | WF1PRO | 4K | Active | No |
| ZHK100B-WF1 Pro Max 4K | WF1 Pro Max 4K | 4K | Active | No |
| ZHK100B-WF1 Pro Max 4K HG | WF1 Pro Max 4K HG | 4K | Active | No |
| ZHK100B-Sound Max 4K | Sound Max4K | 4K | Active | Yes |
| ZHK100B-Sound Max 5 | Sound Max5 | HD | Active | Yes |
| ZHK100B-Sound Max 5 HG | Sound Max5 HG | HD | Active | Yes |
1. According to the quantity of the mounting brackets and appropriate distance, you should install the brackets at the suitable position on the wall with screws.
2. Hang the screen on the wall.
| Ultra Thin Frame Projection Screen | ||||||||||
| Format | Size | View Area | Frame Size | Package Size | Frame Width(mm) | |||||
| (inch) | W*H(mm) | Frame Length(L) | Frame Width(A) | L(mm)*W(mm)*H | ||||||
| 16:9 | 80" | 1771 | 996 | 1795 | 1020 | 1983*342*148 | 12 | |||
| 90" | 1992 | 1120 | 2016 | 1144 | 2204*342*148 | 12 | ||||
| 100" | 2213 | 1245 | 2237 | 1269 | 2425*342*148 | 12 | ||||
| 110" | 2435 | 1369 | 2459 | 1393 | 2647*342*148 | 12 | ||||
| 120" | 2656 | 1494 | 2680 | 1518 | 2868*342*148 | 12 | ||||
| 135" | 2988 | 1681 | 3012 | 1705 | 3200*342*148 | 12 | ||||
| 140" | 3099 | 1743 | 3123 | 1767 | 3311*342*148 | 12 | ||||
| 150" | 3320 | 1867 | 3344 | 1891 | 3532*342*148 | 12 | ||||
| 160" | 3542 | 1992 | 3566 | 2016 | 3680*342*148 | 12 | ||||
| 170" | 3763 | 2116 | 3787 | 2140 | 3754*342*148 | 12 | ||||
| 180" | 3984 | 2241 | 4008 | 2265 | 2596*240*264 | 12 | ||||
| 200" | 4427 | 2490 | 4451 | 2514 | 2847*240*264 | 12 | ||||
| 4:3 | 100" | 2032 | 1524 | 2056 | 1548 | 2244*342*148 | 12 | |||
| 120" | 2438 | 1828 | 2462 | 1852 | 2650*342*148 | 12 | ||||
| 150" | 3048 | 2286 | 3072 | 2310 | 3260*342*148 | 12 | ||||
| 180" | 3657 | 2743 | 3681 | 2767 | 3869*240*264 | 12 | ||||
| 200" | 4064 | 3048 | 4088 | 3072 | 3399*240*264 | 12 | ||||
| 2.35:1 | 120″ | 2804 | 1193 | 2828 | 1217 | 3016*342*148 | 12 | |||
| 135″ | 3155 | 1342 | 3179 | 1366 | 3367*342*148 | 12 | ||||
| 150″ | 3505 | 1491 | 3529 | 1515 | 3717*342*148 | 12 | ||||
| 180″ | 4206 | 1790 | 4230 | 1814 | 2300*240*264 | 12 | ||||
| 200″ | 4674 | 1989 | 4698 | 2013 | 2534*240*264 | 12 | ||||
Supporting Customized Size
Size From 80" to 200" are available in any ratio
